galvanised steel coils price

galvanised steel coils is a thin steel plate with Q235 as the base material immersed in melted zinc tank, so that its surface adhesion of a layer of zinc thin steel plate. It is mainly produced by continuous galvanizing process, that is to make galvanized steel coil by continuous dipping of steel plate in the plating tank of melted zinc.

Classification :

Coil Series

Galvanized Steel Coil

+8619863575698

nucorsteel@nucorsteel.cn

E-mail

PRODUCT DETAILS

Galvanized steel coil is a thin steel plate with Q235 as the base material dipped into a melted zinc groove, so that its surface is adhered to a layer of zinc. It is mainly produced by continuous galvanizing process, that is, the rolled steel plate is continuously dipped in the melting zinc bath to make galvanized steel coil.

Product name	Galvanized steel coil
Technical Standard	AISI, ASTM, BS, DIN, GB, JIS
Steel Grade	Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490,SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement
Type	Coil/Sheet/Plate/Strip
Thickness	0.12-6.00mm,or customer's requirement
Width	600mm-1500mm, according to customer's requirement
Type of Coating	Hot Dipped Galvanized Steel(HDGI)
Zinc Coating	30-275g/m2
Surface Treatment	Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)
Surface Structure	Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS)
Quality	Approved by SGS,ISO
Coil Weight	3-20 metric ton per coil
Package	Water proof paper is inner packing,galvanized steel or coated steel sheet is outer packing , side guard plate,then wrapped by seven steel belt.or according to customer's requirement
Export market	Europe, Africa, Central Asia, Southeast Asia, Middle East, South America, North America, etc
