Aluminum coil is a kind of metal sheet, melted by aluminum ingot, plus different alloy, through casting rolling or hot rolling, cold rolling, annealing, shear and other processes into aluminum coil. Aluminum coil has small density, light weight, easy to handle, can be strengthened, plasticity, good thermal conductivity. So it is widely used in power plant and chemical plant pipeline insulation, heat exchanger, evaporator, heating appliances, cooking utensils, etc.

Classification :

Coil Series

Aluminum Coil

+8619863575698

nucorsteel@nucorsteel.cn

E-mail

PRODUCT DETAILS

Product name	Aluminium coil / Aluminium roll
Standard	JIS G3141,DIN1623,EN10130
Thickness	0.15-6.0mm（Support customization）
Width	914mm,1000mm,1219mm,1220mm,1250mm（Support customization）
Temper	O, H12, H22, H32, H14, H24, H34, H16, H26, H36, H18, H28, H38, H19, H25, H27,H111, H112,H241, H332, etc.
Surface Treatment	Mill Finished, Anodized, Embossed, PVC Coated etc
Alloy		Application field
1xxx	1050	Insulation, food industry, decoration, lamp, traffic signs etc.
	1060	Fan blade, Lamps and lanterns, Capacitor shell, Auto parts, Welding parts.
	1070	Capacitor, Rear panel of vehicle refrigerator, charging point, heat sink etc
	1100	Cooker, building material, printing, heat exchanger, bottle cap etc
2xxx	2A12 2024	Aircraft structures, rivets, aviation, machinery, missile components, the card wheel hub, propeller components, aerospace parts,car parts and various other structural parts.
3xxx	3003 3004 3005 3105	Aluminum curtain wall panel, aluminum Ceiling, Electric cooker bottom, TV LCD backboard, storage tank, curtain wall, building construction panel heat sink, billboard. Industrial floor, air conditioning, refrigerators radiators, Make-up board, Prefabricated house etc.
5xxx	5052	Marine and transportation material, railway carriage's inner and outer cabinet, oil and chemical industry storage device,equipment and medical device panel etc.
	5005	Marine applications, bodies of boats, buses, trucks and trailer. Curtain wall panel.
	5086	Ship board, deck, bottom and edge panel etc.
	5083	Tanker, oil storage tank, drilling platform, ship board, deck, bottom, welded parts and edge panel, railway carriage 's board,automotive and aircraft panel, cooling device and automotive molding etc. board,automotive and aircraft panel, cooling device and automotive molding etc.
	5182
	5454
	5754	Tanker body, marine facilities, pressure container, transportation etc.
6xxx	6061	Railway inside and outside parts, board and bed plate. Industry molding Highly stressed applications includes Roofing construction,transportation, and marine as well as mould.
	6083
	6082
	6063	Auto parts, architectural fabrication, window and door frames, aluminum furniture, electronic components as well as various consumer durable products.
7xxx	7005	Truss, rod/bar and the container in transportation vehicles; Large-sized heat ex changers.
	7050	Molding (bottles) mode, ultrasonic plastic welding mold, golf head, shoe mold, paper and plastic molding, foam molding, lost wax mold, templates, fixtures, machinery and equipment.
	7075	Aerospace industry, military industry, electronic etc.
